We’re excited to be part of the team, led by EllisDon Infrastructure Healthcare (EDIH), that will build the new Bayers Lake Community Outpatient Centre in Nova Scotia. HH Angus’ Health Division will be providing mechanical consulting engineering services, working with Dillon Consulting in Halifax. This is the first P3 healthcare project in Nova Scotia, and will be an important facility for both the community and the entire province. According to Kim Spencer, HH Angus Health Division Director, “we’re very pleased to be able to support this new facility with HH Angus’ deep experience in the P3 delivery model, and proven track record in thoughtful healthcare design.”

The 134,000 ft2 Outpatient Centre will built on a 15-acre site in Halifax’s Bayers Lake Business Park. Planned services include primary care; clinics such as physio and occupational therapy; high blood pressure, diabetes and orthopedic assessment; 17 examination rooms; 24 dialysis stations; diagnostic imaging (x-rays and ultrasounds); blood collection; and post-surgery or post-treatment follow-up appointments.

Image courtesy of EDIH

Is your facility and its electrical infrastructure prepared?

As electric vehicles (EVs) become more prevalent, they present a challenge for institutional-type facilities that have significant on-site parking, in terms of how to address the charging requirements of EV owners. Toronto’s Sunnybrook Health Sciences Centre (SHSC) is one such facility. With a three million ft2 campus and 4,535 parking spots, vehicular traffic exceeds 10,000 cars per day.

In 2018, SHSC was experiencing power outages in parking lots due to EV owners using adapters and extension cords to charge their vehicles from housekeeping receptacles. Recognizing the growing demand for on-site charging and wishing to promote green initiatives, SHSC investigated available incentive programs for an EV charging project.

HH Angus was engaged to assist SHSC in delivering this project. The first decision was to identify the type and number of charging stations that would best meet the needs within the established budget. One of the first decisions was which charging level to provide of the three levels available. Level 2 was selected, offering a full charge in four to six hours.

Key considerations for the supply of EV charging stations included physical construction and design features (for example, retractable charging cords were an important feature); service agreements; built-in wireless connectivity; and warranty coverage. It was also necessary to address the increased electrical load for the parking lots through power distribution upgrades and modifications to existing switchgear.

An important decision with direct impact on the installation design was the selection of dual-head EV charging stations, which allow two adjacent vehicles to be serviced by a single charging station. SHSC eventually installed 20 dedicated EV charging stations.

The entire project was successfully completed in approximately four months. By undertaking the necessary project planning, institutional facilities can help ensure their parking areas are ready to meet the requirements of EV owners and further support of green initiatives.

Philip Chow, P.Eng., P.E., was the lead engineer on the project and is a senior project manager at H.H. Angus & Associates Ltd. He specializes in electrical projects and construction in critical facilities and can be reached at philip.chow@hhangus.com.

Bavan Poologarajah,EIT., was the senior electrical designer on the project and worked on the project from initial concept design to final commissioning. Bavan has worked on a number of electrical projects in critical facilities and can be reached at Bavan.Poologarajah@hhangus.com.

HH Angus' Akira Jones and Melissa Parry will be participating in a webinar on May 29 discussing how we used 3D imaging to streamline the process for Toronto Western Hospital's mechanical and electrical facilities.

For more information and to register, click here to try Matterport >

Join us in Montreal on Oct 16 as HH Angus presents “Making a Super Hospital Work” at the Canadian Centre for Healthcare Facilities conference.

As the mechanical, electrical and security design engineers for CHUM, the HH Angus team has unique insight into what it took to successfully deliver the largest healthcare project in North America – the Centre hospitalier de l’Université de Montréal. Nick Stark, Marianne Lee and Phil Schuyler, principals of HH Angus and team leaders, will detail some of the key challenges and solutions for this mega hospital project. Conference attendees will also be able to tour public, clinical, mechanical and electrical facilities at CHUM.

HH Angus is engineering mechanical and electrical systems for three underground stations on the Metrolinx Eglinton Crosstown Light Rail Transit project – Mt. Pleasant, Bayview and Laird Stations. The ECLRT will run along a 19 kilometre corridor following Eglinton Avenue, including a 10 kilometre underground portion. Click here, to see the latest tunnel fly through video.
